TK 1005 H D4F

Designed Specifically For The Shotcrete Contractor

The Putzmeister TK 1005 HD has plenty of power with a 127 hp (95 kW) Caterpillar CAT 3.6 diesel engine and a maximum output of 65 yd³/hr (50 m³/hr). With this, you can push low slump shotcrete mixes long distances with little loss of volume.

Key Features

Fuel-economic automatic speed drawdown on pump stop
High-quality wear resistant components for service-life
Clear operating data and engine status indication via the display
CE mark

General Information

Output

50 m³/hr
Delivery Pressure

101 bar
Max. Aggregate Size

32 mm
Strokes

46
Engine

CAT 3.6
Engine Power

95 kW
Delivery Cylinder Diameter - Stroke Length

180/1000 mm
Hopper capacity

approx. 300 l
Pressure Connection

125 mm
Length x Width x Height

4785x1726x2125 mm
Weight

3350 kg
Trailer Type

F8/F80

Documents

Brochures

Thomkatt TK 1000 Brochure US

pdf | 2 MB

Thomkatt TK 1000 Brochure US

pdf | 2 MB
